Features of TCK56X1200 Turning-Milling Compound Lathe 1. Structural Design Integrated Turning & Milling: Combines CNC turning and milling in one machine, enabling complex part processing without repositioning. Large Machining Capacity: Max Turning Diameter: 560 mm Max Turning Length: 1200 mm Spindle Bore: ≥Φ80 mm (allows long bar feeding) High Rigidity Bed: Cast iron construction with optimized rib design for vibration damping and stability. 2. Precision & Performance High-Speed Spindle: Turning Spindle: 2,000–3,500 rpm (optional geared or direct-drive) Milling Spindle: 6,000–8,000 rpm (with C-axis contouring) Positioning Accuracy: ≤0.008 mm (X/Z axes) Live Tooling: Y-axis milling capability (±50 mm travel) for off-center drilling/tapping. 3. Automation & CNC Features Multi-Axis Control: Standard X, Z, C axes; optional Y-axis and B-axis for 5-sided machining. CNC System: Compatible with Siemens 828D/FANUC 0i-TF (user-programmable macros). Automatic Tool Changer (ATC): 8–12-station turret (VDI 30/40 interface). 4. Material & Application Flexibility Wide Material Range: Steel, stainless steel, aluminum, brass, and composites. Typical Parts: Flanges, shafts, valves, aerospace components. 5. Optional Configurations Tailstock: Hydraulic programmable tailstock (150 mm quill travel). Coolant System: High-pressure coolant (70 bar) for difficult-to-machine materials. Bar Feeder: Compatible with Ø20–65 mm bar feeders. 6. Safety & Maintenance Full Enclosure: Chip and coolant containment with safety interlocks.

CNC Surface Grinding Machine: Characteristics and Advantages The CNC Surface Grinding Machine is a core piece of equipment in modern precision manufacturing. Utilizing computer numerical control technology, it achieves high-precision, high-efficiency grinding of surfaces like planes, grooves, and contours. Its main characteristics and advantages are as follows: Core Characteristics High-Precision Digital Control Employs CNC systems (e.g., Siemens, Fanuc) to precisely control wheel feed rate, table movement speed, and path via programmed instructions. Positioning accuracy can reach ±0.001 mm, with repeat positioning accuracy ≤ 0.002 mm. Supports complex contour programming (e.g., angles, steps, arcs), enabling non-planar form grinding. Integrated Full Automation Functions Automatic Dressing System: Uses diamond rollers for in-process wheel dressing to maintain cutting sharpness. Automatic Measurement & Compensation: Probes detect workpiece dimensions in real-time, automatically compensating for grinding allowance. Automatic Wheel Balancing: Reduces vibration, ensuring superior surface finish (up to Ra 0.1 μm). Rigid Structure & Thermal Stability Machine bed constructed from high-rigidity cast iron (e.g., Meehanite) paired with linear guideways/hydrostatic guideways for excellent vibration resistance. Temperature-Controlled Cooling System: Maintains grinding fluid temperature (±0.5°C), minimizing thermal distortion effects on accuracy. Modular Process Expansion Optional accessories include rotary tables (multi-station machining), magnetic/vacuum chucks (preventing thin-part distortion), and high-pressure washdown systems (efficient swarf removal). Core Advantages Superior Precision & Consistency vs. Manual Machines Maintains dimensional tolerance stability within ±0.002 mm for batch production. Flatness ≤ 0.005 mm / 1000 mm. Ideal for ultra-precision applications like molds, precision bearings, and semiconductor ceramics. Significantly Enhanced Production Efficiency Unattended Continuous Production: Automated loading/unloading + programmed grinding cycles enable 24/7 operation (e.g., batch processing of automotive piston rings). Fast Changeover: Stored part programs allow quick job switching by recalling files, drastically reducing setup time. Reduced Reliance on Operator Skill Traditional grinding relies heavily on technician experience. CNC systems standardize processes through programming, minimizing human error. Breakthrough Capability for Complex Machining Completes combined surface and contour grinding in a single setup (e.g., turbine blade root slots, cutting tool edges), eliminating multiple machining steps. Optimized Total Cost of Ownership Reduces scrap rates (especially for high-value materials like carbide). Lowers labor costs by over 60% (one operator can monitor multiple machines).
