Product Details
Place of Origin: China
Brand Name: Luyoung
Certification: CE
Model Number: M7150x2000
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD25000-USD45000
Packaging Details: non-fumigation wooden box
Delivery Time: 30 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100sets
Condition: |
New |
After-sales Service Provided: |
Online Support,Video Technical Support |
Warranty: |
12 Months |
Weight: |
6000kg |
Voltage: |
380v/220v |
Automatic Grade: |
Semi-Automatic |
Production Capacity: |
High |
Product Name: |
Semi-Automatic Winding Machine |
Machine Type: |
Horizontal |
Color: |
Customizable |
Condition: |
New |
After-sales Service Provided: |
Online Support,Video Technical Support |
Warranty: |
12 Months |
Weight: |
6000kg |
Voltage: |
380v/220v |
Automatic Grade: |
Semi-Automatic |
Production Capacity: |
High |
Product Name: |
Semi-Automatic Winding Machine |
Machine Type: |
Horizontal |
Color: |
Customizable |
M7150x2000mm Metal Grinding Machine with High Precision and Performance
Specifications:
| Main technical parameters | unit | M7150×2000 | |
| Workbench | Workbench size (width x length) | mm | 500×2000 |
| Maximum grinding size (width x length x height) | mm | 500×2000 | |
| Longitudinal movement of worktable (hydraulic) | mm | 200-2100 | |
| Workbench speed (stepless speed regulation) | m/min | 3-25 | |
| Number of T-slots on workbench | 3 | ||
| width | mm | 18 | |
| Workbench load capacity (including electronic suction cup) | kg | 1600 | |
| Electronic suction cup size (width x length) | mm | 500×1000 (2 pieces) | |
| Grinding head | Large lateral movement of grinding head | mm | 500 |
|
Grinding head transverse feed (stepless speed regulation) continuous Intermittent |
mm/min mm/times |
0.8-3 5-25 |
|
| Vertical hand wheel small scale | mm | 0.01 | |
| Vertical feed of grinding head per hand wheel rotation | mm | 0.5 | |
| Grinding wheel size (outer diameter x width x inner diameter) | mm | Φ 350 × 40 × Φ 127 | |
|
Motor power |
Total capacity of electrical equipment | KVA | 20 |
|
Grinding head motor power Speed |
KW r/min |
7.5 1440 |
|
|
Work Accuracy |
Parallelism of the machined surface to the base surface | mm | 300:0.02 |
| Work piece surface roughness | μm | Ra0.63 | |
|
Complete Machine parameter |
Machine tool dimensions (approx.) (length x width x height) | mm | 5000 ×1875×2400 |
| Net weight (approx.) | Kg | 6300 |
Main performance characteristics:
The horizontal surface grinder of the machine tool and the precision rectangular surface grinder screw are made of special alloy steel through strict processing and heat treatment technology. Vertical and rapid lifting of grinding heads to improve production efficiency.
The lateral movement of the grinding head is driven by a hydraulic motor or can be manually operated.
The lifting mechanism and triangular bracket adopt an eccentric design, which is easy to adjust and greatly extends the service life of the machine tool.
Application:
Suitable for various processing machinery, automotive parts, fixtures, magnets, and mold parts processing industries. Machine tools can grind steel, iron, ceramics, and non-ferrous metal parts.
