Product Details
Place of Origin: China
Brand Name: Luyoung
Certification: CE
Model Number: M194
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD70000-USD160000
Packaging Details: non-fumigation wooden box
Delivery Time: 45 working days
Payment Terms: L/C, T/T
Supply Ability: 30/SET
Maximum Work Piece Diameter: |
600mm |
Maximum Work Piece Length: |
4000mm |
Grinding Diameter: Max./min.: |
600mm/40mm |
Maximum Work Piece Weight: |
400kg |
Total Motor Power: |
43.11KW |
Grinding Wheel Size: |
750x100mm |
Maximum Work Piece Diameter: |
600mm |
Maximum Work Piece Length: |
4000mm |
Grinding Diameter: Max./min.: |
600mm/40mm |
Maximum Work Piece Weight: |
400kg |
Total Motor Power: |
43.11KW |
Grinding Wheel Size: |
750x100mm |
| parameter | |
| Maximum work piece diameter | 600 mm |
| Maximum work piece length | 4000 mm |
| Maximum work piece weight | 4000 kg ( with bracket ) |
| Grinding diameter: max./min. | 600mm /40mm |
|
Processing accuracy: Maximum deviation of cylindricity (800 mm length) - Maximum roundness deviation -Surface roughness Ra |
0.010 mm 0.003 mm 0.3 0 microns |
| Worktable feed speed (step-less speed regulation) | 0.05-3.7 m/min |
|
Maximum rotation angle of upper workbench: - Clockwise -Counterclockwise |
0.30° 6.0° |
| Total motor power | 43.11 kW |
| Grinding wheel size | 750x100 mm |
|
Insertion cycle feed (measured in radius) |
0.0025-0.03 mm |
| Vernier scale value | 0.0025 mm |
| Grinding wheel drive motor power | 30 kW |
| Work piece speed (step-less speed regulation) | 5-80 rpm |
| Tailstock sleeve movement | 100 mm |
| Machine weight | 15 tons |
| Machine tool dimensions: | 11000x1700x1750 |
Massive: "Massive" effectively conveys the sense of great size and capacity required for handling 4-meter workpieces and heavy loads. Alternatives like "Large" or "Big" are too generic.
Rigorous: "Rigorous" captures the meaning of being extremely sturdy, strict, and uncompromising in construction for stability. "Robust" or "Sturdy" are also good, but "Rigorous" emphasizes the demanding nature of the requirement.
Precise: "Precise" is the direct and universally understood term for high accuracy in machining. "Precision" (as a noun) could also start the point ("Precision:"), but "Precise" maintains the adjective pattern.
Smart: "Smart" is widely used in manufacturing contexts (Smart Factory, Smart Manufacturing) to indicate intelligence, advanced control, and automation capabilities inherent in modern CNC systems. "Intelligent" is also perfectly valid.
