Product Details
Place of Origin: China
Brand Name: Luyoung
Certification: CE
Model Number: M194
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD70000-USD160000
Packaging Details: non-fumigation wooden box
Delivery Time: 45 working days
Payment Terms: L/C, T/T
Supply Ability: 30/SET
Maximum Work Piece Diameter: |
600mm |
Maximum Work Piece Length: |
4000mm |
Grinding Diameter: Max./min.: |
600mm/40mm |
Maximum Work Piece Weight: |
400kg |
Total Motor Power: |
43.11KW |
Grinding Wheel Size: |
750x100mm |
Maximum Work Piece Diameter: |
600mm |
Maximum Work Piece Length: |
4000mm |
Grinding Diameter: Max./min.: |
600mm/40mm |
Maximum Work Piece Weight: |
400kg |
Total Motor Power: |
43.11KW |
Grinding Wheel Size: |
750x100mm |
| Attribute | Value |
|---|---|
| Maximum work piece diameter | 600mm |
| Maximum work piece length | 4000mm |
| Grinding diameter: max./min. | 600mm/40mm |
| Maximum work piece weight | 400kg |
| Total motor power | 43.11KW |
| Grinding wheel size | 750x100mm |
| Processing accuracy: Maximum deviation of cylindricity (800 mm length) | 0.010 mm |
| Maximum roundness deviation | 0.003 mm |
| Surface roughness Ra | 0.3 microns |
| Worktable feed speed (step-less speed regulation) | 0.05-3.7 m/min |
| Maximum rotation angle of upper workbench (Clockwise/Counterclockwise) | 0.30°/6.0° |
| Insertion cycle feed (measured in radius) | 0.0025-0.03 mm |
| Vernier scale value | 0.0025 mm |
| Grinding wheel drive motor power | 30 kW |
| Work piece speed (step-less speed regulation) | 5-80 rpm |
| Tailstock sleeve movement | 100 mm |
| Machine weight | 15 tons |
| Machine tool dimensions | 11000x1700x1750 |
